Quick Details

  • Place of Origin: Henan, China (Mainland)
  • Brand Name: tianrui
  • Model Number: Customer's Requirements
  • Color: White

Packaging & Delivery

Packaging Details carton
Delivery Time 7days
Company profile
Product Description

USES:
(1) the filter element shall be installed in the suction port of the pump:
Pump on the oil absorption of generally are equipped with surface type oil filter, purpose is to filter the bigger impurity particles in order to protect the hydraulic pump, in addition oil filter filtration ability should be more than twice of pump flow, pressure loss is less than 0.02 MPa.
(2) the filter element is installed on the outlet of the pump:
The purpose of the filter is to filter the contaminants that may invade the valve class. The filtration precision should be 10 ~ 15 mu m, and can withstand the pressure of work and pressure on the oil road. The pressure drop should be less than 0.35 MPa. Safety valve should be installed in case the filter is blocked.
(3) the filter element is installed on the back oil circuit of the system:
This installation ACTS as an indirect filter. Generally with the filter and even install a back pressure valve, the back pressure valve opens when the filter is blocked to a certain pressure value.
(4) the filter element is installed on the system branch.
(5) filter core single filtration system:
The large hydraulic system can set up a hydraulic pump and filter unit to form an independent filtration circuit.
Filter in the hydraulic system in addition to the oil filter required by the system, and often in some key components (such as servo valves, precision throttle valve, etc.) in the front of the individual to install a dedicated fine oil filter to ensure their normal work.
Performance indicators:
Dielectric: general hydraulic oil phosphate oil emulsion water-oil emulsion water - diol
Material: fiberglass filter paper -BN stainless steel mesh -W wood pulp filter paper -P stainless steel sinter -V
Filtration precision: 1 mu ~ 100 mu
Work pressure: 21bar-210bar
Working medium: general hydraulic oil, phosphatic oil hydraulic oil, emulsion, water - glycol
Working temperature: - 30 ℃ ~ + 110 ℃
Sealing material: fluorine rubber ring, ding gum
Product application:
1. Metallurgy: the filtration of hydraulic system of rolling mill, continuous casting machine and various lubrication equipment.
2, petrochemical, oil refining, chemical products and intermediate products in the process of production of separation and recovery, liquid purification, tape, CD and photographic film in the manufacturing of purification, the well water and gas injection in addition to the particle filter.
3. Textile: the purifying and uniform filtration of the polyester melt in the process of drawing, the protection of air compressor, the removal of oil except water by compressed gas.
4. Electronic and pharmaceutical: reverse osmosis water, deionized water treatment filtration, cleaning liquid and glucose pre-treatment filtration.
5. Thermal power and nuclear power: gas turbine, boiler lubrication system, speed control system, bypass control system oil purification, water pump, fan and dust removal system purification.
6, mechanical processing equipment: papermaking machinery, mining machinery, injection molding machine and large precision machinery lubrication system and compressed air purification, tobacco dust recycling processing equipment and spraying equipment.
7. Railway internal combustion engine and generator: lubricating oil and oil filter.
8. Automotive engine and engineering machinery: the internal combustion engine is used for air filtration, oil filtration, fuel filtration, engineering machinery, ship, heavy truck with various hydraulic oil filtration, diesel filter and water filtration.

Products Show
Packing & Delivery

Packing Details : Packing, carton
Delivery Details : 5-10 days after order of Solid bicycle tire tubes

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 1 day if the goods are in stock. or it is 7-10 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
